GR-200 series LiF:Mg,Cu,P TLD is a kind of solid detector. It is the use of heating method, make detector by radiation energy stored in the form of light released ，it has an extreme low detectable threshold, and is near air or tissue equivalent.
GR-200 series LiF:Mg,Cu,P TLD is a kind of solid detector. It is the use of heating method, make detector by radiation energy stored in the form of light released ，it has an extreme low detectable threshold, and is near air or tissue equivalent. It’s unique features make it an ideal environmental, personal and medical dosimeter per it’s high sensitivity ,Especially in the radioactive field of low background environment, it behaves better than other kind of TLDs for dose monitoring.
Hangzhou Freqcontrol Electronic Technology Ltd. has been working with our National Chemical defense organization on R/D and supply the excellent personal dosimetry chips with different specifications to all of World market. The customed design is available
Specifications For Chips of LiF
Part no 型号 | Type 型号 | Shape 类型 | Application 用途 |
GR-200A | Natural LiF(Mg,Cu,P) | Round Chip 圆片 | personal use；Environmental X-rays, γ rays dosimetry |
GR-200 | Natural LiF(Mg,Cu,P) | Square Chip 方片 | personal use；Environmental X-rays, γ rays dosimetry |
GR-200P | Natural LiF(Mg,Cu,P) | powder 粉末 | personal use；Environmental X-rays, γ rays dosimetry |
GR-200F | Natural LiF(Mg,Cu,P) | Skin(beta) 薄膜 | β dosimetry β 剂量测量 |
GR-200T | Natural LiF(Mg,Cu,P) | Capillary Tube 毛细管 | personal use；Environmental X-rays, γ rays dosimetry |
GR-200R | Natural LiF(Mg,Cu,P) | Rod 棒 | personal use；Environmental X-rays, γ rays dosimetry |
GR-206 | 6LiF(Mg,Cu,P) (enriched Li-6) | various sizes 各种规格 | Mixing field neutron measurement 混合场中子测量 |
GR-207 | 7LiF(Mg,Cu,P) (enriched Li-7) | various sizes 各种规格 | Mixed field γ-ray dosimetry 混合场 γ 射线剂量测量 |
GR-100 | LiF(Mg,Ti) | Round/Square Chip、powder 圆、方片、粉末 | X-rays, γ rays dosimetry X-射线γ 射线剂量测量 |
GR-100M | LiF(Mg,Ti-M) | Round/Square Chip、powder 圆、方片、粉末 | X-rays, γ rays dosimetry X-射线γ 射线剂量测量 |
Parameter 参数 | GR-200A | GR-100M | GR-100 |
Linear dose range[Gy]线性范围[Gy] | 10-7~12 | 5x10-5 -500 | 10-4~8 |
Detectable threshold[Gy]探测阀[Gy] | ~10-7 | 1.1x10-5 | 1.4x10-5 |
Relative TL sensitivity to TLD-100 | 65 | 5 | 1.3 |
Consistency 一致性 | <3% | <5% | <5% |
Energy dependence (photon: 30keV ~3MeV )能量响应 | <20% | <20% | <30% |
Thermoluminescent Dosimeter (TLD) Chips are advanced solid-state radiation detectors designed to accurately measure ionizing radiation by storing absorbed energy within the crystal lattice and releasing it as light when heated. This thermoluminescence principle enables highly precise and reliable dose measurement across a wide range of radiation monitoring applications.
CQT GROUP supplies high-performance LiF:Mg,Cu,P Thermoluminescent Dosimeter Chips (GR-200 Series) featuring exceptional sensitivity, excellent tissue equivalence, low detection thresholds, and outstanding dose linearity. These characteristics make them ideal for personal dosimetry, environmental radiation monitoring, medical physics, nuclear power plants, research laboratories, and homeland security applications.
Thermoluminescent Dosimeter Chips operate by absorbing energy from ionizing radiation such as X-rays, gamma rays, beta particles, or other radiation sources. The absorbed energy is trapped within the crystal structure of the detector material.
During the readout process, the chip is heated in a TLD reader, causing the trapped electrons to return to their normal state and emit visible light. The intensity of the emitted light is directly proportional to the absorbed radiation dose, allowing for precise quantitative measurement.
This passive detection method provides excellent long-term stability and does not require an external power source during radiation exposure.
Ultra-High Sensitivity
LiF:Mg,Cu,P is recognized as one of the most sensitive thermoluminescent materials available, offering significantly higher sensitivity than conventional LiF:Mg,Ti detectors.
Benefits include:
Extremely low detectable dose threshold
Excellent response to low-dose radiation
High measurement accuracy
Reliable monitoring in low-background environments
Excellent Tissue Equivalence
The effective atomic number of LiF:Mg,Cu,P closely matches that of human tissue, enabling highly accurate personal radiation dose assessment with minimal energy dependence.
Advantages include:
Accurate personal dosimetry
Improved dose evaluation
Reliable occupational radiation monitoring
Wide Dose Measurement Range
Thermoluminescent Dosimeter Chips can measure radiation over a broad dose range while maintaining excellent linearity and repeatability.
Suitable for:
Low-level environmental monitoring
Occupational exposure monitoring
Medical radiation measurement
Industrial radiation protection
Outstanding Stability
The chips provide excellent storage stability with low signal fading, allowing radiation doses to be retained for extended periods before readout.
Key advantages include:
Long-term signal retention
Stable measurement results
Excellent repeatability
Reliable long-term monitoring
Superior Radiation Resistance
LiF:Mg,Cu,P TLD Chips exhibit excellent resistance to repeated irradiation and annealing cycles, making them suitable for multiple reuse under proper processing conditions.
Product Advantages
High thermoluminescence efficiency
Extremely low detection threshold
Excellent dose linearity
Low background signal
Near tissue-equivalent response
High chemical stability
Good thermal stability
Reusable through proper annealing
High reproducibility
Long service life
Available Materials
CQT GROUP supplies Thermoluminescent Dosimeter Chips in various detector materials, including:
LiF:Mg,Cu,P (GR-200 Series)
LiF:Mg,Ti
Custom TLD materials upon request
Customized detector dimensions and specifications are available for different radiation monitoring systems.
Personal Radiation Dosimetry
TLD Chips are widely used for monitoring occupational radiation exposure of personnel working in radiation environments.
Applications include:
Nuclear power plants
Hospitals
Medical imaging departments
Radiation therapy centers
Industrial radiography
Research laboratories
Environmental Radiation Monitoring
Due to their exceptional sensitivity, LiF:Mg,Cu,P chips perform particularly well in low-background environments.
Typical applications include:
Environmental radiation surveys
Background radiation monitoring
Nuclear facility perimeter monitoring
Emergency response systems
Public radiation safety programs
Medical Dosimetry
Thermoluminescent Dosimeter Chips are commonly used in medical physics for accurate radiation dose verification.
Applications include:
Radiotherapy dose verification
Diagnostic radiology
CT dose monitoring
Brachytherapy
Patient dose assessment
Quality assurance (QA)
Industrial Radiation Measurement
Industrial sectors use TLD Chips for monitoring radiation exposure in manufacturing and inspection processes.
Applications include:
Non-destructive testing (NDT)
Industrial irradiation
Radiation processing
Oil and gas inspection
Aerospace testing
Scientific Research
Research institutions utilize high-sensitivity TLD Chips in various radiation experiments and detector development projects.
Applications include:
Particle physics
Nuclear science
Space radiation studies
University laboratories
Radiation detector calibration
CQT GROUP supplies premium Thermoluminescent Dosimeter Chips for customers in healthcare, nuclear energy, environmental monitoring, scientific research, and industrial radiation protection.
Our advantages include:
High-quality LiF:Mg,Cu,P detector materials
Consistent manufacturing quality
High sensitivity and repeatability
Strict quality inspection
Multiple chip dimensions available
Custom specifications supported
OEM and ODM manufacturing
Technical support from experienced engineers
Worldwide shipping and responsive customer service
